MORE DURABLE MILL BEARINGSOUTSIDE DIAMETER SIZE RANGE OF100MM- 1 1590MM
Details
Thrust tapered roller bearing | ||||||||||||||||||||
Model | Boundary Dimensions(mm) | Basic rated load(KN) | Calculated parameters | Refer to the weight(kg) | Reference code | |||||||||||||||
d | D | B | T | C | H | Fw | Cr | Cor | e | Y1 | Y2 | Y0 | lnner ring | Bearing | SKF | FAG | NTN | NSK | TMKE | |
8292/900 | 900 | 1180 | 48 | 220 | 4500 | 22000 | 580 | 522834 | ||||||||||||
8292/670 | 670 | 900 | 50 | 230 | 3580 | 19000 | 425 | 351761A | 521823 | |||||||||||
8297/600k | 600 | 910 | 70 | 290 | 4730 | 21200 | 655 | 350901C | ||||||||||||
8297/600 | 600 | 880 | 70 | 290 | 4730 | 21200 | 550 | BFDB350824B/HA1 | ||||||||||||
8297/550 | 550 | 760 | 50 | 230 | 2920 | 13200 | 310 | 350976C | 515196 | |||||||||||
8292/530 | 530 | 710 | 57 | 218 | 2700 | 14000 | 245 | 351475C | 511746 | |||||||||||
829796 | 480 | 710 | 57 | 218 | 2700 | 14000 | 280 | 547584 | ||||||||||||
829794 | 470 | 720 | 60 | 200 | 3410 | 19300 | 305 | BFDB3533238/HA3 | 549701 | |||||||||||
829994 | 470 | 720 | 50 | 200 | 3410 | 19300 | 285 | 353151 | 509391 | |||||||||||
829990k | 450 | 645 | 38 | 155 | 2240 | 12200 | 157 | 513401 | ||||||||||||
829990 | 450 | 645 | 38 | 155 | 1980 | 10800 | 170 | 350916D | ||||||||||||
829788k | 440 | 660 | 35 | 155 | 2450 | 12300 | 178 | 523720 | ||||||||||||
829788 | 440 | 645 | 50 | 167 | 2240 | 12700 | 190 | 353152 | 534038 | |||||||||||
829984k | 420 | 620 | 50 | 185 | 2280 | 12000 | 202 | 545991 | ||||||||||||
829784k | 420 | 620 | 50 | 185 | 2420 | 12200 | 200 | BFDB353200/HA3 |
Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Always a pre-production sample before mass production;
Always final Inspection before shipment;
During the epidemic, provide remote detection technical support
Tell us a little about your application and we’ll get back to you to finalize a quotation to meet your needs as quickly as possible.
Are You Looking for rolling mill rolls? – contact us to get best plan.
