MORE DURABLE MILL BEARINGSOUTSIDE DIAMETER SIZE RANGE OF100MM- 1 1590MM
Application：
rolling mill, cold rolling mill, hot rolling mill and maintenance
Addvantage：
LMMGROUP rolling mill bearings can replace import bearings that great save the purchase cost.
Certification:
ISO 9001, ISO 14001 and OHSAS 18001
Details
Double row angular contact ball bearing | ||||||||||||||||||||
Model | Boundary Dimensions（mm) | Basic rated load（KN） | Calculated parameters | Refer to the weight（kg） | Reference code | |||||||||||||||
d | D | B | T | C | H | Fw | Cr | Cor | e | Y1 | Y2 | Y0 | lnner ring | Bearing | SKF | FAG | NTN | NSK | TMKE | |
40/560X2D | 560 | 820 | 230 | 900 | 2100 | 390 | ||||||||||||||
49/560D | 560 | 750 | 190 | 950 | 2500 | 230 | ||||||||||||||
40/530X2DC | 530 | 780 | 224 | 930 | 3380 | 335 | ||||||||||||||
49/530X2DC | 530 | 760 | 200 | 815 | 2890 | 275 | ||||||||||||||
40/500X2D | 500 | 720 | 200 | 1020 | 2700 | 260 | ||||||||||||||
49/500X2D | 500 | 670 | 156 | 860 | 2400 | 156 | ||||||||||||||
4096X2D | 480 | 700 | 200 | 1000 | 2600 | 240 | ||||||||||||||
4092X2D | 460 | 680 | 200 | 1100 | 2800 | 240 | ||||||||||||||
4992X2D | 460 | 620 | 148 | 810 | 2000 | 116 | ||||||||||||||
4088X2D | 440 | 650 | 188 | 720 | 2340 | 200 | ||||||||||||||
4084X2D | 420 | 620 | 180 | 870 | 2100 | 177 | ||||||||||||||
4984X2D | 420 | 560 | 130 | 590 | 1300 | 89.0 | ||||||||||||||
4080X2D | 400 | 600 | 180 | 952 | 2000 | 170 | ||||||||||||||
4980X2D | 400 | 540 | 130 | 530 | 1210 | 84.0 | ||||||||||||||
4076X2D | 380 | 560 | 164 | 468 | 1520 | 133 | ||||||||||||||
Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Always a pre-production sample before mass production;
Always final Inspection before shipment;
During the epidemic, provide remote detection technical support
Tell us a little about your application and we’ll get back to you to finalize a quotation to meet your needs as quickly as possible.
We would be happy to help and advise if you have any questions or inquiries.
